SKU: MS-9A66
MS-9A66 Embedded Systems
The MS-9A66 is a high performing box PC which supports 4th Gen Intel Core processors. With an option of either 1x PCIe x16 and 3x PCI slots OR 2x PCIe x8 and 2x PCI slots, this fanless embedded system is perfect for rugged, scalable, and versatile requirements.
Features
- 4th Gen Intel® Core i7/i5/i3/Pentium®/Celeron® processor
- Fanless design to support Intel® 4th Gen CPU (up to 35W)
- 3 independent display supported
- Wide range 9~36V DC power input
- Supports AT power mode
- Optional system fan module
- Supports 4 expansion slots: 1x PCIe x16; 3x PCI OR 2x PCIe x8; 2x PCI
- GPIO supports 5~24V for automation
- Removable cover for easy maintenance
- Supports DAQ, video capture and VGA card for PCI express slot
- Dimensions: 175mm x 225mm x 218mm
Features
DESCARGAR FICHA
| CPU Socket Type | LGA 1150 |
| Chipset | Intel Q87 Express or Intel C226 |
| Channel Supported | Dual Channel |
| CPU Type | Core i7 / i5 / i3 / Pentium / Celeron |
| Number of Memory Slots | 2x204pin |
| Memory Standard | 1600 / 1333 DDR3 (non-ECC) |
| Maximum Memory Supported | 16GB |
| PCIe 3.0 x16 | 1 (Q87 chipset) |
| PCIe 3.0 x8 | 2 (C226 chipset) |
| PCI | 2 (C226 chipset) |
| SATA 3.0 | 2 |
| CFast | 1 |
| Graphic Controller | Intel HD Graphics (C226 chipset) |
| DVI-I | 1 |
| DisplayPort | 2 |
| Display Mode | 3x independent |
| Audio Controller | Realtek ALC887 HD Audio Codec |
| Ethernet Controller | 1x Intel I210-AT GbE LAN |
| PS/2 | 1x Keyboard/Mouse |
| USB 3.0 | 4 |
| USB 2.0 | 3 |
| Serial | 5x COM |
| Serial Types | COM1 (RS-232/422/485 0V/5V/12V) |
| Watchdog Timer | 256-level |
| TPM | 1x Infineon SLB9635TT1.2 |
| Power Supply | DC-In 9-36V Wide-Range pluggable connectors with latch (GND, V-, V+) |
| Operating Temperature | -10-50 C |
| Operating Humidity | 10-90% non-condensing |
| Storage Temperature | -20-80 C |
| Storage Humidity | 10-90% non-condensing |
| Regulatory Compliance | FCC, CE, C-Tick, VCCI, BSMI, TUV |
