SKU: AD-291

AD-291 2U Industrial Rack Mount Computer

The AD-291 2U industrial rack mount computer may be only 2U high, but it incorporates 6-slots enabling the AD-291 to accept a variety of single board computers and other PCI/ISA cards. The locking front door protects both floppy and CD-ROM drives in harsh environments, while the built-in fan keeps things cool. The design of the AD-291 allows for horizontal installation of full-size single board computers and room for add-on cards. Its an excellent choice when you need a compact computer that’s big on performance and convenience.

Features

DESCARGAR FICHA

Features

  • 2U chassis height
  • Accepts up to 6-slot backplanes
  • External bays: 1 x 3.5″, 1 x 5.25″
  • Internal bays: 1 x 3.5″
  • Removable «wings» for rack or desktop operation
  • Front door protects disk drives
  • Front panel supports keylock and power switch, reset button & dual USB
  • Dual ball-bearing fans with filters keep things cool
  • Supports PS/2 power supplies
  • Shock: 10 G acceleration peak to peak (11 ms)
  • Vibration: 5~17Hz, 0.1″ double amplitude displacement; 17~640Hz, 1.5 G acceleration peak to peak
  • Dimensions: 18.9″ W x 3.4″ H x 17.1″ D
